Description
High Quality Water and Moisture Filtration Unit
The Best for Bodyshop and Workshop pneumatic Installations!
Max operating pressure: 12 bar Outlet: 0,5-10 bar Pressure gauge part size: G 1/8
TECHNICAL SPECIFICATIONS
- Temperature: +5°C to +50 °
- Construction: Body : Aluminium
Polycarbonate bowl with metallic protection - Equipped with: Manual drain
| SKU | BSPP female thread | Flow rate (l/min at 6 bar ΔP=0.3bar) | Max operating pressure (bar) | Filtration (µm) |
|---|---|---|---|---|
| TF 2 | G 3/8 | 2250 | 12 | 25 |
| TF205 | G 3/8 | 2250 | 12 | 5 |
DIMENSIONS
| Ref | A (mm) | B (mm) |
|---|---|---|
| TF 2 | 55 | 140 |
| TF 205 | 55 | 140 |
