Description
Professional Multi-Process Welding Solution For Workshop And Field Applications
The GYS MULTIPEARL 210-2 (065093) is a versatile multi-process power source designed for high-precision welding across MIG/MAG (with or without gas), TIG DC, and MMA applications. This 4-in-1 inverter welder features advanced PFC (Power Factor Correction) technology that delivers 30% energy savings compared to traditional welders while enabling operation with generator power or extended cable lengths up to 100m. Capable of handling material thicknesses from 0.6mm to 6mm, the MULTIPEARL 210-2 offers dual voltage capability (110V/230V) with adjustable welding parameters to suit various applications. With 9 welding synergies that enable welding in all positions, this compact 16kg unit combines workshop-grade performance with field mobility, making it the perfect companion for professional welders who demand precision and versatility.
Specification
- Supply voltage: Dual 230V – 110V with 50/60 Hz mains frequency
- Adjustable welding current: 20-200A (230V) / 20-130A (110V) for MMA; 20-200A (230V) / 20-160A (110V) for TIG
- Dimensions: 250 x 450 x 350 mm with 16 kg weight
- Power consumption: 7.5 kW
- Maximum compatible generator power: 9 kVA
- Reference standard: EN 60974-1 (40°C) for MIG
- Welding thickness capability: 0.6 to 6 mm
Features
- Multi-process capability: MIG/MAG (with or without gas), TIG DC and MMA welding functions
- PFC (Power Factor Correction) technology delivering 30% energy savings compared to traditional welders
- Compatible with motor generators and extended cable operations up to 100m
- 9 welding synergies for optimal performance in all welding positions
- Adjustable Arc Force (0-100%) for optimized arc stability
- Anti-sticking function to reduce electrode sticking risks
- SPOT and DELAY functions for precision tack welding
FAQs
1. What accessories are provided with the GYS MULTIPEARL 210-2?
The GYS MULTIPEARL 210-2 comes complete with a ground cable (2.50m), a 250A MIG steel torch (3m), and an electrode holder (2m), providing everything needed to begin welding immediately after purchase.
2. Can the GYS MULTIPEARL 210-2 be used with a generator on remote job sites?
Yes, the GYS MULTIPEARL 210-2 is designed to work with generators up to 9 kVA capacity. Its PFC technology allows it to function efficiently with motor generators or with cable extensions up to 100m, making it ideal for remote job sites.
3. What is the maximum material thickness that can be welded with this machine?
The GYS MULTIPEARL 210-2 can effectively weld sheet metal ranging from 0.6mm to 6mm in thickness, making it suitable for a wide range of applications from light sheet metal work to moderate structural fabrication.
4. How does the dual voltage capability affect welding performance?
The dual voltage capability (110V/230V) allows for flexible operation in various environments. At 230V, you can achieve maximum power with welding currents up to 200A for both MMA and TIG applications. When operating at 110V, the machine offers reduced but still highly functional output ranges: 20-130A for MMA and 20-160A for TIG welding.
