Description
3-in-1 Multi-Process MIG-MAG, No-Gas & MMA Inverter Welder
The GYS EASYMIG 140 is a compact 3-in-1 inverter welding machine designed for versatility and ease of use in small workshops, garages, and maintenance environments. It combines MIG/MAG with gas, No-Gas flux-cored, and MMA (stick) welding processes in one lightweight unit. Delivering up to 140A output, it is suitable for welding steel, stainless steel, and aluminium on sheet thicknesses up to 3mm. Featuring a simplified interface with easy voltage and wire speed adjustments, the EASYMIG 140 ensures stable arc performance and clean results even for novice users. Its inverter technology guarantees excellent current control, reduced energy consumption, and high-quality weld consistency. Built with a reinforced chassis, integrated wire feeder, and ergonomic handle, this ultra-light 7.8kg unit offers exceptional portability and durability — making it perfect for both indoor and outdoor applications.
WHY BUY FROM BWS?
.bws-benefits { max-width: 800px; margin: 0 auto; padding: 10px;}.image-container { display: flex; justify-content: left; gap: 10px; margin-bottom: 15px;}.benefit-image img { width: 100px; height: 100px; object-fit: contain; margin-bottom: 16px;}@media (max-width: 600px) { .image-container { flex-direction: column; align-items: left; }}
Specification
- Reference: 032262
- Power Supply: 230V Single Phase (16A)
- Welding Current Range: 20 – 140A (MMA) / 20 – 120A (MIG/MAG)
- Duty Cycle: 15% @ 140A / 60% @ 70A
- Wire Diameter: Ø 0.6 – 0.9 mm (solid or flux-cored)
- Electrode Diameter: Ø 1.6 – 3.2 mm
- Wire Feed Speed: 3 – 9 m/min
- Voltage Range: 15 – 21V
- Dimensions: 38 × 16 × 35 cm
- Weight: 7.8 kg
- Protection Rating: IP21
Features
- 3-in-1 Multi-Process Welder: MIG/MAG, flux-cored (No-Gas), and MMA capabilities in one unit.
- Compact and Portable: Weighs only 7.8 kg with ergonomic handle and reinforced structure.
- Inverter Technology: Ensures precise arc stability, low energy use, and improved weld quality.
- Integrated Wire Feeder: Built-in 2-roller feeder for 100 mm (1 kg) wire reels.
- Gas/No-Gas Functionality: Quick polarity reversal allows fast switching between processes.
- Thermal and Power Indicators: Dual LED lights provide real-time machine status monitoring.
- Ready-to-Weld Kit: Supplied with torch, earth clamp, electrode holder, contact tip, and gas accessories.
- Robust Construction: Reinforced casing with shock-absorbing pads for workshop and mobile work.
FAQs
1. What welding processes does the EASYMIG 140 support?
It supports MIG/MAG (gas), flux-cored (No-Gas), and MMA (stick) welding, offering complete flexibility for different materials and conditions.
2. Can this welder be used outdoors?
Yes, it’s ideal for outdoor use when operating in No-Gas mode with flux-cored wire, which eliminates the need for shielding gas.
3. What materials can the EASYMIG 140 weld?
It can weld steel, stainless steel, and aluminium using the correct wire and gas setup.
4. Is the EASYMIG 140 suitable for beginners?
Yes, its simplified controls and pre-configured settings make it easy to operate even for entry-level welders.
