Description
SIP KP200W-Ac Kohler Welder Generator
SKU 25167
The SIP KP200W-AC is a powerful petrol welder generator designed to provide mobile welding solutions for various tasks, as well as offer auxiliary outputs for use as a standalone generator.
- 230v / 115v input supply
- Kohler 14hp petrol engine
- 7KVA max. rated generator output
- 60A – 200A ARC (AC) output current
- High 180A @ 60% generator duty cycle
- 7.3litres (2.8hours) fuel tank and runtime
- 1.5mm – 8mm approx. weld thickness range
- 1.6mm – 5mm maximum electrode diameter
- Steel-forged crankshafts, Stellite® exhausts
- Oversized muffler / oversized ignition system
- Quad Clean™ heavy-duty cyclonic air cleaner
- Engine designed by Kohler in the USA
- Assembled and tested by SIP in UK
- 3 year Kohler engine warranty
TECHNICAL DESCRIPTION
| Electric Start | No |
| Engine Type | Kohler 14hp OHV |
| Output Current | 60A – 200A (AC) |
| Open Circuit Voltage | 45v – LO / 60v – HI |
| Generator Duty Cycle | 180A @ 60% |
| Electrode Diameter ∅ | 1.6mm – 5mm |
| Welding Thickness | 1.5mm – 8mm |
| Generator Supply | 230v / 115v |
| Generator Output | 7KVA |
| Fuel Tank Capacity | 7.3litres |
| Full Load Run Time | 2.8hours |
| Insulation | Class H |
| Protection | IP21 |
| Gross Weight | 90kg |
| Packaged Dimensions | 820(H) x 800(W) x 1200mm(D) |
