Description
SKU 25169
The SIP HP200W-AC ES is a powerful petrol welder generator designed to provide mobile welding solutions for various tasks, as well as offer auxiliary outputs for use as a standalone generator.
- Electric-starting model
- 230v / 115v input supply
- Honda GX390 petrol engine
- 7KVA max. rated generator output
- 60A – 200A ARC (AC) output current
- High 180A @ 60% generator duty cycle
- 7.3litres (2.45hours) fuel tank and runtime
- 1.5mm – 8mm approx. weld thickness range
- 1.6mm – 5mm maximum electrode diameter
- Inclined cylinder and a counterbalance shaft
- Low oil shutdown helps prevent damage
- Hot spark ignition, splash-fed lubrication
- Excellent and efficient fuel consumption
- Reduced oil consumption for longer life
- Assembled and tested by SIP in UK
- 3 year Honda engine warranty
TECHNICAL DESCRIPTION
| Electric Start | Yes |
| Engine Type | HONDA GX390 |
| Output Current | 60A – 200A (AC) |
| Open Circuit Voltage | 45v – LO / 60v – HI |
| Generator Duty Cycle | 180A @ 60% |
| Electrode Diameter ∅ | 1.6mm – 5mm |
| Welding Thickness | 1.5mm – 8mm |
| Generator Supply | 230v / 115v |
| Generator Output | 7KVA |
| Fuel Tank Capacity | 7.3litres |
| Full Load Run Time | 2.45hours |
| Insulation | Class H |
| Protection | IP21 |
| Gross Weight | 90kg |
| Packaged Dimensions | 820(H) x 800(W) x 1200mm(D) |
