ETC-1 AVR Generator Spare Parts ETC-1 AVR Automatic Voltage Regulator for Generator
DESCRIPTION:
Type:AVR
Condition: new，replacement
PMN:ETC-1
Manufacturer Warranty: 1 Year
Input Voltage
Jumper selectable 95-132V ac or 190-264V ac
Frequency 50-60Hz 2Phase/2wire
Output Voltage
max 90V dc at 207V ac input
Current continuous 4 A dc
Intermittent 7.5 A for 10secs
Resistance
15 ohms minimum
Regulation
±1.5%(With 4% engine governing)
Typical System Response
AVR response 20 ms
External Voltage Adjustment
±5% with 1 k ohm 1 watt trimmer
Under Frequency Protection
set point 47 Hz
Unit Power Dissipation
10 watts maximum
Build Up Volitage
5 volts @ AVR terminals
Note:
1. Please make sure it will fit your machine before purchasing it. If you are not 100% sure this is what you need, please find out your engine model, series number and contact our Customer-service.
2. Please double check the part number of your item, matching information is for reference only.If you are unsure of the item, please contact us before buying to avoid unnecessary return, thanks!
3. Communication is the best way to solve the problem. If you have any problems after you receive the package, please contact us in time, before opening a return or case.
4.For more information please contact us info@diselmart.com. We will reply you in 24 hours.
