Versatile 3-in-1 MIG-MAG, No-Gas and MMA Inverter Welder
The GYS EASYMIG 150 is a highly capable 3-in-1 inverter welding machine that combines MIG/MAG with gas, No-Gas flux-cored, and MMA (stick) welding in one portable and powerful unit. Delivering up to 140A of output, it is ideal for small workshops, maintenance tasks, and light fabrication on steel, stainless steel, and aluminium. This semi-automatic welder features a simplified front panel for easy adjustment of voltage and wire speed, ensuring smooth, stable arc performance even for novice users. Equipped with inverter technology for superior current control and low energy consumption, it provides excellent weld quality with reduced spatter. Compact, durable, and weighing only 9.6 kg, the EASYMIG 150 includes an integrated wire feeder, removable Euro torch, and reinforced chassis with shock-absorbing pads — making it perfect for both indoor workshop and outdoor applications.
WHY BUY FROM BWS?
.bws-benefits { max-width: 800px; margin: 0 auto; padding: 10px;}.image-container { display: flex; justify-content: left; gap: 10px; margin-bottom: 15px;}.benefit-image img { width: 100px; height: 100px; object-fit: contain; margin-bottom: 16px;}@media (max-width: 600px) { .image-container { flex-direction: column; align-items: left; }}
Specification
- Reference: 032248
- Power Supply: 230V Single Phase (16A)
- Welding Current Range: 20 – 120A (MIG/MAG) / 30 – 140A (MMA)
- Duty Cycle: 15% @ 140A / 60% @ 70A
- Wire Diameter: Ø 0.6 – 0.9 mm (steel, stainless, aluminium)
- Electrode Diameter: Ø 1.6 – 3.2 mm
- Wire Speed: 3 – 10 m/min
- Voltage Range: 15 – 21V
- Dimensions: 40 × 20 × 33 cm
- Weight: 9.6 kg
- Protection Rating: IP21
Features
- 3-in-1 Multi-Process Welder: MIG/MAG, flux-cored (No-Gas), and MMA stick welding capabilities in one compact unit.
- Dual Wire Compatibility: Accepts both 100mm (1kg) and 200mm (5kg) wire reels for added flexibility.
- Removable Euro Torch: 150A torch (2.2m) allows quick connection and easy maintenance.
- Gas/No-Gas Functionality: Polarity reversal system enables fast setup for cored wire welding.
- Integrated Wire Feeder: Built-in 2-roller drive ensures stable wire feed and smooth operation.
- Thermal Protection & LED Indicators: Dual status lights for power and overheating alerts.
- Lightweight & Portable: Weighs only 9.6 kg with ergonomic handle and reinforced chassis.
- Inverter Technology: Provides high arc stability, improved weld quality, and reduced energy use.
- Shock Absorbing Pads: Protects the unit from vibration and impact during transport.
FAQs
1. What welding processes does the EASYMIG 150 support?
It supports MIG/MAG with gas, No-Gas flux-cored wire welding, and MMA stick welding — offering complete versatility for workshop and field applications.
2. Can I use both 1kg and 5kg wire reels?
Yes, the EASYMIG 150 is compatible with both 100mm (1kg) and 200mm (5kg) wire reels, making it flexible for different welding jobs.
3. Can the machine weld aluminium?
Yes, with the correct aluminium wire and shielding gas setup, the EASYMIG 150 can weld aluminium effectively.
4. Is this welder suitable for outdoor use?
Yes, in No-Gas mode with flux-cored wire, it can be used outdoors as it is not affected by wind.
