Fronius CU 1100I Liquid Cooling System

Description

Brand: Fronius

Fronius TPSI Water Cooler Unit

SKU:  4,048,016

A dedicated water cooling unit for the Fronius TPSI can either be part of a package or installed afterwards.

Specification

Supply voltage                                                          400 V AC
Mains voltage tolerance                                         -10% / + 10%
Mains frequency                                                       50/60 Hz
Current consumption                                              0.7 A
Max. Flow                                                                   3.5 l / min / 0.92 gal. / Min
Max. Pump pressure                                               4.2 bar / 60.92 psi
Pump                                                                          Centrifugal Pump
Pump life approx                                                      10,000 h
Content coolant                                                        6 l / gal 1:59.
Protection                                                                   IP 23
Dimensions l / w / h                                                 710/300/230 mm
Weight (without coolant)                                         13.6 kg
