EA15A EA15A-2 AVR Automatic Voltage Regulator for Generator alternator Genset Power Auto Parts
DESCRIPTION:
Type: AVR
Condition: new，replacement
PMN:EA15A
Manufacturer Warranty: 1 Year
Sensing Input Voltage 190 ~ 500 VAC, 1 phase 2 wire Jumper selectable Frequency 50 / 60 Hz, Jumper selectable
Power Input Voltage 100 ~ 300 VAC, 1 phase 2 wire
Output Voltage Max. 90 VDC @ 240 VAC input Current Continuous 15A Intermittent 20A for 10 sec Resistance Min. 9 ohm
Voltage Regulation < ± 0.5% ( with 4% engine governing )
Voltage Build-up Residual voltage at AVR terminal > 5 VAC
Thermal Drift 0.03% per °C change in AVR ambient
External Volts Adjustment ± 15% with 5K ohm 1 watt trimmer
Unit Power Dissipation Max. 10 watt
Under Frequency Protection ( Factory Setting ) 60 Hz system presets knee point at 55 Hz 50 Hz system presets knee point at 45 Hz
Soft Start Ramp Time 2 sec.
Dimensions 150mm L * 100mm W * 64mm H
Note:
1. Please make sure it will fit your machine before purchasing it. If you are not 100% sure this is what you need, please find out your engine model, series number and contact our Customer-service.
2. Please double check the part number of your item, matching information is for reference only.If you are unsure of the item, please contact us before buying to avoid unnecessary return, thanks!
3. Communication is the best way to solve the problem. If you have any problems after you receive the package, please contact us in time, before opening a return or case.
4.For more information please contact us info@diselmart.com. We will reply you in 24 hours.
