Description
BALMA BELT DRIVEN/STATIC AIR COMPRESSOR -BA3/150BSI-BA3/150BS3
A powerful range of single and three-phase compressors designed with
larger volumes of air and higher working pressures to meet the demands of
professional and industrial applications. Ideal for larger size workshops, or
where higher demands of air and heavier duty applications are required.
All pumps are fitted with a cast iron cylinder for increased cooling
- Full-sized pumps with a large oil sump for increased lubrication reduce the wear of the conrods and further increases the lifetime of the compressor
- Special non-wear construction conrods and robust cast Iron
- Single and three-phase electric motors fitted with thermal overload protection.
- Automatic stop/start pressure switches fitted with soft start
- Machines are fully C certified and manufactured in accordance with EN IS09001
Part No.
230v-BA1/150BSI
400v- BA3/150BS3
SPECIFICATION
|
Air Displacement CFM |
13.9 |
|
Maximum Free Air Delivery CFM |
10.1 |
|
Maximum Pressure |
145psi(10bar) |
|
Minimum Rated Supply |
13A |
|
Motor Output |
3hp |
|
Nett Weight |
87kg |
|
Outlet |
1/2″BSP Female Tap |
|
Receiver Capacity |
150L |
|
Size (W x D x H) |
1380 x 420 x 950mm |
|
Max Pressure |
10 bar |
|
Supply: |
230V |
